Key Features

Advanced MPPT technology with ultra-fast tracking response 12 or 24V Battery 100Voc solar
Tracking efficiency ≥ 99.5% for maximum solar harvest
Built-in Bluetooth on XTRA-N G3 BLE models for app control
Constant voltage output allows PV power directly to loads
Wide MPPT voltage range for flexible panel configuration
Supports lithium, sealed, gel, and flooded batteries
Adaptive three-stage charging with lithium self-activation
Low self-consumption under 10mA for high system efficiency
RS485 communication interface with optional Wi-Fi or 4G modules
Full-load operation across the entire working temperature range
IP33 enclosure with comprehensive electronic protections

Power Output
Array size max 1.5 x power output within 100Voc.

10A - 12V~130W
20A - 12V~260W
30A - 12V~390W
40A - 12V~520W

Applications

The XTRA-N G3 MPPT Controller is engineered for both trade installers and retail users, offering reliable performance for a wide range of mobile and fixed solar systems. Popular with Toowoomba 4WD owners, off-grid setups, RV enthusiasts, and home solar users.

RVs, caravans & motorhomes
Off-grid cabins and tiny homes
Portable & mobile solar systems
Residential solar charging
Field monitoring stations & remote power

Technical Specifications

Series: XTRA-N G3 / XTRA-N G3 BLE
Current Rating: 10A, 20A, 30A, or 40A (model dependent)
Technology: High-efficiency MPPT (≥ 99.5% tracking)
Charging Mode: Adaptive 3-stage charging
Battery Compatibility: Lithium, sealed, gel, flooded
Bluetooth: Integrated (BLE models only)
Communication: RS485 (Wi-Fi/4G optional modules)
Self Consumption: <10mA
Protection Rating: IP33
Electronic Protections: Overload, PV reverse polarity, battery reverse polarity, over-temperature, short circuit and more
Temperature Compensation: Automatic (lead-acid)
PV to Load Function: Yes, constant voltage output

Datasheet

Warranty & Brand Trust

The XTRA-N G3 Series is engineered by EPEVER, a global leader in dependable solar charge technology. Built for long-term reliability with advanced protections and premium components, this controller is trusted by installers and off-grid users worldwide.

2YR Warranty
